🎯 Overview

This web application facilitates the module credit recognition process at Leipzig University. It provides a streamlined workflow for students to submit credit recognition applications and for university staff to review and approve them through a multi-stage approval process.

Overview

Key Features

  • Multi-role System: Student, Student Affairs Office, and Examining Committee interfaces
  • Application Workflow: Complete lifecycle from submission to approval
  • PDF Processing: Automated document handling, storage, and summary generation
  • Multi-language Support: Full internationalization with 10 languages
  • Secure Authentication: JWT-based authentication with role-based access control
  • Real-time Status Updates: Live application status tracking
  • Responsive Design: Mobile-friendly interface built with Vuetify
  • Audit Trail: Complete application history and change tracking

📊 Business Workflow

Application Lifecycle

  1. Student Submission: Students submit module credit recognition applications with supporting documents
  2. Office Review: Student Affairs Office reviews applications for completeness and formal requirements
  3. Committee Approval: Examining Committee evaluates academic merit and makes final decisions
  4. Status Updates: Real-time notifications and status updates throughout the process
  5. PDF Generation: Automated generation of approval/rejection summaries

User Roles & Permissions

  • Students: Submit applications, view status, download summaries
  • Student Affairs Office: Review applications, formal approval/rejection, prepare for committee
  • Examining Committee: Final academic approval/rejection, course equivalency decisions

Application States

  • open - Initial submission
  • edited - Modified by office
  • formally rejected - Rejected due to formal issues
  • ready for approval - Prepared for committee review
  • edited approval - Modified by committee
  • approved - Final approval
  • rejected - Final rejection

🏗️ Architecture

The application follows a microservices architecture with clear separation of concerns:

Web Application Architecture

System Components

Frontend (Vue.js)

  • Views: Role-specific interfaces for different user types
  • Components: Reusable UI components for forms, tables, and navigation
  • Services: API communication layer with axios
  • Store: Centralized state management with Vuex
  • Routing: Client-side routing with Vue Router
  • Internationalization: Multi-language support with Vue I18n

Backend (Spring Boot)

  • Controllers: REST API endpoints for client communication
  • Services: Business logic and core functionality
  • Repositories: Data access layer with JPA/Hibernate
  • Security: JWT authentication and role-based authorization
  • Data Transfer Objects: Structured data exchange between layers
  • Exception Handling: Centralized error management

Database (PostgreSQL)

  • Normalized Schema: Optimized for data integrity and performance
  • Entity Relationships: Complex relationships between applications, modules, and users
  • Audit Logging: Change tracking and history maintenance

🛠️ Technology Stack

Frontend Stack

{
  "framework": "Vue.js 3.2.13",
  "ui": "Vuetify 3.4.0",
  "state": "Vuex 4.1.0",
  "routing": "Vue Router 4.2.5",
  "http": "Axios 1.6.2",
  "i18n": "Vue I18n 9.7.0",
  "testing": "Vitest 0.34.6",
  "linting": "ESLint 8.0.0"
}

Backend Stack

<dependencies>
  <spring-boot>3.2.0</spring-boot>
  <java>17</java>
  <spring-security>JWT-based</spring-security>
  <spring-data-jpa>3.2.0</spring-data-jpa>
  <postgresql>runtime</postgresql>
  <h2>test-scope</h2>
  <lombok>optional</lombok>
  <modelmapper>3.1.1</modelmapper>
  <pdfbox>2.0.29</pdfbox>
</dependencies>

Infrastructure

  • Containerization: Docker & Docker Compose
  • Reverse Proxy: Nginx
  • CI/CD: GitLab CI/CD with automated testing and deployment
  • Monitoring: Application-level logging with SLF4J
